Atlas SUNTEST XLS+

Modern desktop models, ideal instruments for 3D samples, equipped with various easy-to-use accessories, allowing SUNTEST to meet your different needs.

SUNTEST XLS+is used to detect short-term changes in the characteristics of materials and products caused by sunlight, temperature, and moisture. The changes that occur in the product outdoors or indoors, such as fading, yellowing, or strength loss, may take several months or years, while in a SUNTEST testing instrument, it often only takes a few weeks to simulate.

Advantage:

According to CIE85 advanced solar radiation simulation

Simulate window glass filtering sunlight or artificial supermarket lighting

Excellent test chamber design for testing 3D samples

Easy to use touchscreen user interface with 13 language options

Preset standards for convenient and quick startup operations

Black label temperature sensor (BST) compliant with ISO 4892-1 standard

Automatic irradiance control to meet different testing requirements

Optional attachments:

SunSpray spray device for weather aging testing

SunFlood immersion device convenient for testing under extreme humidity conditions

SunCool cooling device for testing in low-temperature environments (such as drugs and beverages)

Characteristic:

Desktop design size 90 x 54 x 62 cm

39 x 30 cm (1170 cm2) exposed area

1 air-cooled 1700 watt xenon lamp tube

Easy to use touchscreen user interface with 13 language options

Directly set and control the irradiation intensity of 300-400 nanometers (including 340 nanometers) or 300-800 nanometers (including Lux)

Directly set and control the black label temperature (BST), BPT optional

Display the temperature of the test chamber

Directly control the tolerance range of each test parameter and optimize test control

Display diagnostic information

10 programmable tests, each containing up to 12 stages

Pre set polymer and coating standards can be quickly called up

Tilt the control panel for comfortable operation

Horizontal exposure area of 1170 cm2. suitable for multiple flat or 3D samples

Advanced daylight simulation based on CIE85

Lamp box equipped with aluminum reflector, lamp tube connector, and filter slot

Long lasting uncoated quartz external filter

Range of irradiance 30-65 W/m2 (300-400 nanometers); 0.26-0.62 W/m2 (340 nanometers) or 250-765 W/m2 (300-800 nanometers); 45-130 klx (Lux)

Design of BST sensor in accordance with ISO 4892-1

Connect to the network through Ethernet interface, refer to optional XenoTouch software attachments 1. 2. and 3 ("Remote Control", "Email Service", "Online Monitoring")

End test mode ": irradiation dose, light exposure time, or total operating time

Advanced automatic start function

Output data through RS232 or memory card

Internal storage chip for storing tool data
